Akuvox single-button SIP video door phone- Standard version
E12S
Product info
Brand
Category
Description
The Akuvox E12S is a state-of-the-art Android indoor monitor intercom designed to elevate your home security and communication experience. With its sleek 7-inch touch screen display and intuitive interface, the E12S seamlessly integrates into your smart home ecosystem. Enjoy crystal-clear video calls, remote door unlocking, and real-time monitoring capabilities. The IOT tech team highly recommends the E12S for its advanced features, reliability, and user-friendly design, making it the perfect addition to any modern and secure home.
PRODUCT DESCRIPTION
The Akuvox® E12S is a state-of-the-art Android indoor monitor intercom designed to elevate your home security and communication experience. With its sleek 7-inch touch screen display and intuitive interface, the E12S seamlessly integrates into your smart home ecosystem. Enjoy crystal-clear video calls, remote door unlocking, and real-time monitoring capabilities. The IOT tech team highly recommends the E12S for its advanced features, reliability, and user-friendly design, making it the perfect addition to any modern and secure home.
FEATURES
- Real-time 2-way talk
- Live camera viewing
- Cloud or local based storage
- Rated for outdoor use
- Mobile App compatible
- Integrated with any SIP device
SPECIFICATION
| At a Glance |
|---|
| Real-time 2-way talk |
| Live camera viewing |
| Cloud or local based storage |
| Rated for outdoor use |
| Mobile App compatible |
| Integrated with any SIP device |
| Physical & Power | |
|---|---|
| Body Material | Plastic |
| Camera | 2M pixels, automatic lighting |
| Button | 1 call button with backlight |
| Wiegand port | Support |
| RF card reader | 13.56MHz |
| Light sensor | 1 |
| Relays out | 1 |
| Inputs | 2 |
| Micro SD card slot | 1 |
| Microphone | -36dB |
| Speaker | 8Ω / 1.5W |
| Ethernet port | RJ45, 10/100Mbps adaptive |
| BLE (Bluetooth) | Yes |
| Vandal alarm | Yes |
| Power | 802.3af Power-over-Ethernet 12V DC connector (if not using PoE) |
| Water-proof & Dust-proof | IP65 |
| Installation | Wall-mounted |
| Size | 146x70x23mm |
| Working Humidity | 10~90% |
| Working Temperature | -40°C ~ +60°C (-40°F ~ 140°F) |
| Storage Temperature | -40°C ~ +70°C (-40°F ~ 158°F) |
| Networking & Protocol | |
|---|---|
| Protocols support | IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP |
| Video | |
|---|---|
| Sensor | 1/2.7”, CMOS |
| Pixels | CIF, QCIF, VGA, 4CIF, 720p, 1080p |
| Video codec | H.264, H.265 |
| Video resolution | up to 1920x1080p |
| Max. image transfer rate | 1080p – 25fps |
| Viewing angle | 123°(H) / 69°(V) |
| White LEDs for picture lighting during dark Hours with internal light sensor | |
| Door Entry Feature | |
|---|---|
| Relays controlled individually by DTMF tones | |
| Camera permanently operational | |
| Auto-night mode with LED illumination | |
| White balance | auto |
| Minimum illumination | 0.1LUX |
| Audio | |
|---|---|
| SIP v1 (RFC2543), SIP v2 (RFC3261) | |
| Narrowband audio codec | G.711a, G.711μ, G.729 |
| Broadband audio codec | G.722 |
| DTMF | In-band, out-of-band DTMF (RFC2833) |
| SIP Info | In-band, out-of-band DTMF (RFC2833) |
| SIP Info | Echo Cancellation |
| Voice Activation Detection | |
| Comfort Noise Generator | |
