Dahua 4MP STARLIGHT BULLET WDR IR60M IP67 2.7~13.5MM

DH-IPC-HFW2431TP-ZAS-S2

Add to wishlist

PRODUCT DESCRIPTION

IOT tech recommends that the Dahua^®LifeSmart^®Akuvox^®

FEATURES

4MP, 1/3” CMOS image sensor, low illuminance, high image definition
Outputs 4MP (2560 × 1440)@25/30 fps, max. supports 4MP (2688 × 1520)@20 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in IR LED, max IR distance: 60 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent detection: Intrusion, tripwire
Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal ac- cess, local alarm, voltage detection,audio abnormal
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 GB Micro SD card
12V DC/PoE power supply
IP67 protection ,IK10 protection (optional)

SPECIFICATION

Lens
Lens Type	Motorized vari-focal
Mount Type	φ14
Focal Length	2.7 mm–13.5 mm
Max. Aperture	F1.5
Field of View	Horizontal: 104°–27°Vertical: 55°–15°Diagonal: 124°–31°
Iris Type	Fixed
Close Focus Distance	0.8 m–0.8 m (2.62 ft–2.62 ft)

Video
Video Compression	H.265; H.264; H.264B; MJPEG (only supported by thesub stream)
Smart Codec	Smart H.265+/ Smart H.264+
Video Frame Rate	Main stream:2688 × 1520 (1 fps-20 fps)2560 × 1440 (1 fps-25/30 fps)Sub stream:704 × 576 (1 fps-25 fps)704 × 480 (1 fps-30 fps)
Stream Capability	2 streams
Resolution	2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440);2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 ×480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control	CBR/VBR
Video Bit Rate	H.264: 32 kbps–6144 kbpsH.265: 12 kbps–6144 kbps
Day/Night	Auto(ICR)/Color/B/W
BLC	Yes
HLC	Yes
WDR	120 dB
White Balance	Auto/natural/street lamp/outdoor/manual/regionalcustom
Gain Control	Auto/Manual
Noise Reduction	3D NR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest(RoI)	Yes (4 areas)
Smart Illumination	Yes
Image Rotation	0°/90°/180°/270° (Supports 90°/270° with 2688 ×1520resolution and lower.)
Mirror	Yes
Privacy Masking	4 areas

Audio
Audio Compression	G.711a; G.711Mu; G.726

Alarm
Alarm Event	No SD card; SD card full; SD card error; networkdisconnection; IP conflict; motion detection; videotampering; tripwire; intrusion; illegal access; voltagedetection; audio detection; safety exception; local alarm

Network
Network	RJ-45 (10/100 Base-T)
SDK and API	Yes
Cyber Security	Video encryption; firmware encryption; configurationencryption; Digest; WSSE; account lockout; security logs;IP/MAC filtering; generation and importing of X.509certification; syslog; HTTPS; 802.1x; trusted boot; trustedexecution; trusted upgrade
Protocol	IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP;RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP;NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone;Genetec
User/Host	20
Storage	Dahua Cloud; FTP; Micro SD card (support max. 256 G);NAS; SFTP
Browser	IEChromeFirefox
Management Software	Smart PSS; DSS; DMSS
Mobile Phone	IOS; Android
